| Chemical Formula | Mo2B |
| Catalog No. | ST0925 |
| CAS Number | 12006-99-4 |
| Purity | 99.9%, 99.95%, 99.99%, 99.995%, 99.999% |
| Shape | Discs, Plates, Column Targets, Step Targets, Custom-made |
The Molybdenum Boride Sputtering Target is available in various forms, purities, sizes, and prices. Stanford Advanced Materials (SAM) boasts extensive experience in providing Molybdenum Boride Sputtering Targets with both high purity and competitive pricing.
Molybdenum Boride Sputtering Target is used in a process called sputtering, which is a technique for depositing thin films onto a substrate. In sputtering, high-energy ions bombard a target material, causing atoms or molecules to be ejected from the target surface. These ejected particles then form a thin film on a substrate.
Applications of Molybdenum Boride Sputtering Targets are often used in the production of coatings for various purposes, such as improving the wear resistance of tools, enhancing the durability of surfaces, or providing specific optical or electrical properties.
Related Product: Molybdenum Boride Sputtering Target (Mo2B5)
| Compound Formula | Mo2B |
| Molecular Weight | 202.69 |
| Appearance | Gray target |
| Melting Point | 2000 |
| Density (g/cm3) | 9.2 |
| Available Sizes | Dia.: 1.0″, 2.0″, 3.0″, 4.0″, 5.0″, 6.0″
Thick: 0.125″, 0.250″ |
Molybdenum Boride Sputtering Target is widely used in the production of coatings for tools, electronic devices, or other surfaces where these properties are desirable.
Our Molybdenum Boride Sputtering Target is widely used in the production of coatings for various purposes, such as improving the wear resistance of tools, enhancing the durability of surfaces, or providing specific optical or electrical properties.
SAM’s Molybdenum Boride Sputtering Target is available in various forms, purities, and sizes. We specialize in producing high-purity physical vapor deposition (PVD) materials with the highest possible density and smallest possible average grain sizes for use in semiconductor, chemical vapor deposition (CVD), and physical vapor deposition (PVD) display and optical applications.
