OFHC Copper Backing Plates

Machined from oxygen-free, high-conductivity copper.

For regular, circular disc-type sputtering sources
Most sputter sources accept a 0.125″ (1/8″) thick target bonded to a 0.125″ thick backing plate
For targets of other thicknesses, choose the backing plate thickness to adjust the total thickness to 0.250″ (1/4″) to suit most applications

Ordering Table

Target
Size		 PartNo Price
Target
Size		 PartNo Price
1.0″ x 0.0625″
 EJBPCU01A1 $75.00
1.0″ x 0.125″
 EJBPCU01A2 $40.00
1.3″ x 0.125″
(With Magnetic Keeper)
 EJBPCU01.3K+ $75.00
2.0″ x 0.0625″
 EJBPCU02A1 $70.00
2.0″ x 0.125″
 EJBPCU02A2 $50.00
2.0″ x 0.125″
(With Magnetic Keeper)
 EJBPCU02K2 $75.00
2.00″ x 0.092″ (For Torus 2)
 EJBPCU02T2 $50.00
3.0″ x 0.0625″
 EJBPCU03A1 $80.00
3.0″ x 0.125″
 EJBPCU03A2 $60.00
3.0″ x 0.125″
(With Magnetic Keeper)
 EJBPCU03K2 $95.00
3.00″ x 0.092″ (For Torus 3)
 EJBPCU03T2 $60.00
4.0″ x 0.0625″
 EJBPCU04A1 $85.00
4.0″ x 0.125″
 EJBPCU04A2 $70.00
4.00″ x 0.092″ (For Torus 4)
 EJBPCU04T2 $70.00
5.0″ x 0.0625″
 EJBPCU05A1 P.O.R.
5.0″ x 0.125″
 EJBPCU05A2 $110.00
6.0″ x 0.0625″
 EJBPCU06A1 P.O.R.
6.0″ x 0.125″
 EJBPCU06A2 $130.00
6.0″ x 0.125″
(With Magnetic Keeper)
 EJBPCU06K2 P.O.R.
6.0″ x 0.250″
 EJBPCU06A4 $195.00
7.0″ x 0.125″
 EJBPCU07A2 $140.00
7.0″ x 0.250″
 EJBPCU07A4 P.O.R.
8.0″ x 0.125″
 EJBPCU08A2 $150.00
8.0″ x 0.250″
 EJBPCU08A4 P.O.R.
TORUS 10 Full
(6.375″ x 0.50″)
 EJBPT10FULL P.O.R.

Send an inquiry here
