Chemical Formula: N-type Silicon
Catalog Number: ST0043
CAS Number: 7440-21-3
Shape: Discs, Plates, Column Targets, Step Targets, Custom-made
Silicon is a chemical element originated from the Latin ‘silex’ or ‘silicis’, meaning flint. It was first mentioned in 1824 and observed by J. Berzelius. The isolation was later accomplished and announced by J. Berzelius. “Si” is the canonical chemical symbol of silicon. Its atomic number in the periodic table of elements is 14 with location at Period 3 and Group 14, belonging to the p-block. The relative atomic mass of silicon is 28.0855(3) Dalton, the number in the brackets indicating the uncertainty.
|Material Type||N-type Silicon|
|Color/Appearance||Dark Gray with a Bluish Tinge, Semi-Metallic|
|Melting Point||1,410 °C|
|Thermal Conductivity||150 W·m-1·K-1 (25°C)|
|Thermal Expansion||2.6 x 10-6/K (25°C)|
|Available Sizes||Dia.: 1.0″, 2.0″, 3.0″, 4.0″, 5.0″, 6.0″
Thick: 0.125″, 0.250″
We also offer other customized shapes and sizes of the sputtering targets, please send us an inquiry for more information.
Indium Bonding is available for N-type Silicon Sputtering Target. Stanford Advanced Materials is devoted to machining standard backing plates and working together with the Taiwan Bonding Company for providing bonding services. For questions about target bonding materials, methods and services, please click here.
The N-type Silicon sputtering target is used for thin film deposition, decoration, semiconductor, display, LED and photovoltaic devices, functional coating as nicely as other optical information storage space industry, glass coating industry like car glass and architectural glass, optical communication, etc.
Other applications of silicon are:
Our N-type Silicon sputter coater target is clearly tagged and labeled externally to ensure efficient identification and quality control. Great care is taken to avoid any damage which might be caused during storage or transportation.
SAM’s N-type Silicon sputtering targets are available in various forms, purities, sizes, and prices. We specialize in producing high purity film coating materials with the highest possible density and smallest possible average grain sizes for use in semiconductor, chemical vapor deposition (CVD) and physical vapor deposition (PVD) display and optical applications. Please send us an inquiry for current pricing on sputtering targets and other deposition materials not listed.
