OX1321 Niobium Monoxide Powder

Catalog No. OX1321
Purity 99%-99.999%
CAS Number 12034-57-0
Chemical Formula NbO
Appearance Grey powder

Supplier of Niobium Monoxide Powder

Stanford Advanced Materials (SAM) provides high purity niobium monoxide powder.




Description

Niobium Monoxide Powder Description

Niobium monoxide powder is a grey solid powder with metallic conductivity. It is also a superconductor at 1.38 K. NbO powder is often used in capacitors for its high capacitance and low ESR.

niobium monoxide powder

Niobium Monoxide Powder Specifications

Grade Impurity Physical Property Electrical property
O
%
N
ppm
Bulk Density
g/cm3
Particle Size
μm
Inspection Instruction
Weight
g/pc
Density
g/cm3
Sintering Condition
°С/min
Voltage
V
Weight Volume
μFV/g
Leakage Current
μA/μFV
Max.
Breakdown Voltage
V
Min.
NM-0011 14.7-15.4 300-3000 1.0-1.3 41706 0.15 2.8 1460/10 30/21 65000 5×10-4 80
NM-0012 14.7-15.4 300-3000 0.9-1.25 41676 0.15 2.8 1460/10 30/21 80000 5×10-4 78
NM-0013 14.7-15.4 300-3000 0.8-1.2 1-4.5 0.15 2.8 1380/10 30/21 120000 5×10-4 70

Niobium Monoxide Powder Applications

Niobium monoxide powder (NbO powder) is used in capacitors where a layer of Nb2O5 is formed around NbO grains as the dielectric.

Niobium Monoxide Powder Packing

1KG/25KG, or as required
Our niobium monoxide powder is clearly tagged and labeled externally to ensure efficient identification and quality control. Great care is taken to avoid any damage which might be caused during storage or transportation.
